FEATURES
- Compact design, saves space
- Available with flush type, projecting type, selector, lock & key, emergency stop
- Available in illuminated & non-illuminated type with square & round shapes
- Momentary & latching function available
- With standard inbuilt combination of 1NO+1NC
- Other customized combinations possible
- IP65 after mounting on panels
- Available in 24V DC, 110V AC and 240V AC
- Mechanical life of 1 million cycles & electrical life of 0.1 million cycles
- Solder/Quick connect terminals
| Test Parameters | Specification |
|---|---|
| Rated Voltage | 250V AC/DC |
| Minimum Applicable Load | 5V AC/DC, 1mA |
| Terminal Style | 110 solder/quick connect |
| Operating Humidity | 45 to 85% RH |
| Contact Resistance | 50M Ω maximum |
| Vibration Resistance | 10 to 55Hz, amplitude 1.2mm p-p |
| Contact Configuration | Single pole, double pole |
| Thermal Current | 5A |
| Operating Temperature | -25°C to +55°C |
| Degree of Protection | >10g |
| Insulation Resistance | 100M Ω minimum (500V DC megger) |
| Mechanical Life | Maintained : 1,000,000 operations minimum |
| Electrical Life | 100,000 operations minimum (at full rated load) |
| Contact material | Gold-plated silver |
